JIC Female 37° Flare Swivel – 60° – Global Spiral

Gates Global Spiral female JIC hose couplings are part of a two-piece coupling specifically designed for use on Gates’ range of hydraulic hoses.

Global Spiral Couplings – Suits EFG3K, EFG4K, EFG5K, EFG6K

PDF document icon D3 – Fittings for Spiral Hose – Product Download

GSJF60 (2)

MJ Hydraulic Part Number Gates Desc Gates Part Number Hose ID Thread Size H1   H2 T L   C
inch mm mm mm mm  mm mm
GSJF60-17-12¥ 12GS-12FJX60-043 7347-76795 3/4 19.1 1 1/16-12 1 1/8 1 1/4 43.0 142.0 91.0

¥ Pricing & availability on request, contact us. Minimum purchase quantity may apply.

Gates eCrimp provides the most up-to-date crimp specifications for all Gates hose and fitting combinations.


The Gates GlobalSpiral Coupling is a no-skive, easy to use coupling which provides a high quality performance and can be used for extremely high-pressure and high-impulse hydraulic applications. The no-skive ferrule abolishes the need for skiving equipment while also reducing labour and assembly time as well reducing odours, contamination from dust and assembly errors.

FULL-TORQUE NUT™ DESIGN – One of the most common causes of hydraulic leaks is a cracked coupling nut or seat due to over-torquing by a strong-armed worker. Gates has engineered a solution – Full-Torque Nut™ technology now available on Gates MegaCrimp and GlobalSpiral® couplings.
