G2XH 2 Wire Braid Extreme Heat Hose SAE 100R2 Type AT

Clear

Description

G2XH 2 Wire Braid Extreme Heat Hose SAE 100R2 Type AT

Recommended For: High Pressure hydraulic applications where pressure or temperature requirements exceed SAE 100R2AT Type S and EN 853 2SN or where resistance to either petroleum-base or phosphate ester fluids is required.
Tube: Black, Specifically compounded for temperature and chemical resistance. (CPE – Type J)
Reinforcement: Two braids of high-tensile steel wire.
Cover: Blue, oil and abrasion resistant thin synthetic rubber (CSM – Type M).

Temperature Range: Petroleum based fluids -40°C to +149°C. Phosphate ester fluids as recommended by the fluid
manufacturer, but within a range of -40°C to +100°C. For water emulsions: Max +107°C pressure lines, Max +82°C return lines.

Fittings: (see crimp manuals for specifics):
MegaCrimp® Fittings (except -24 and -32).

PDF document icon D1 Hydraulic Hose – Product Download

MJ Hydraulic Part Number Gates Desc. Hose ID Working pressure (PSI/Bar) Min. Burst pressure (PSI/Bar) Min. bend radius (inch/mm) Approx. bulk carton length (ft/M)
inch mm
G2XH-04 4657-2541 1/4 0.580 6000 / 413 24000 / 1654 4.000 / 102 550 / 167
G2XH-06 4657-2542 3/8 0.730 5000 / 345 20000 / 1378 5.000 / 127 400 / 121
G2XH-08 4657-2543 1/2 0.860 4250 / 293 17000 / 1172 7.000 / 178 330 / 100
G2XH-10 4657-2544 5/8 0.980 3625 / 241 14500 / 999 8.000 / 203 220 / 67
G2XH-12 4657-2545 3/4 1.140 3100 / 214 12400 / 854 9.500 / 241 220 / 67
G2XH-16 4657-2546 1 1.480 2400 / 165 10000 / 689 12.000 / 305 165 / 50
G2XH-20 ¥ 4657-4005 1 1/4 1.870 2250 / 155 9000 / 620 16.500 / 419 120 / 36

¥ Pricing & availability on request, contact us. Minimum purchase quantity may apply.

Additional information

Model

G2XH-04, G2XH-06, G2XH-08, G2XH-10, G2XH-12, G2XH-16, G2XH-20
