G2 2 Wire Braid Hose – SAE 100R2 Type AT
$123.480 – $177.625 ex GST
Description
G2 2-Wire Braid Hose – SAE 100R2 Type AT
G2 2-Wire Braid Hose in sizes -04 through -16 is being phased out for the next generation of hose.
Refer to MXT Wire Braid Hose for sizes -04 through -16 which exceeds the performance of G2.
Recommended For: High Pressure hydraulic oil lines. Meets or exceeds the requirements of SAE 100R2AT and SAE 100R2 types and performance requirements of EN 853 2SN.
Tube: Black, oil-resistant synthetic rubber (Nitrile-Type C)
Reinforcement: Two braids of high-tensile steel wire.
Cover: Black, oil and abrasion resistant thin synthetic rubber (Modified Nitrile)
Temperature Range: -40°C to +100°C
Fittings: (see crimp manuals for specifics):
PC Fittings for -03
MegaCrimp® Fittings (except -24 and -32).
GSP Fittings for -24 and -32
D1 Hydraulic Hose – Product Download
| MJ Hydraulic Part Number | Gates Desc. | Hose ID | Working pressure (PSI/Bar) | Min. Burst pressure (PSI/Bar) | Min. bend radius (inch/mm) | Approx. bulk carton length (ft/M) | |
| inch | mm | ||||||
| G2-03¥ | 4657-0020 | 3/16 | 0.520 | 6000 / 410 | 24000 / 1654 | 3.500 / 89 | 425 / 130 |
| G2-04 | 4657-0125 | 1/4 | 0.580 | 5800 / 400 | 23200 / 1598 | 4.000 / 102 | 550 / 167 |
| G2-06 | 4657-0126 | 3/8 | 0.730 | 4800 / 331 | 19200 / 1323 | 5.000 / 127 | 400 / 121 |
| G2-08 | 4657-0127 | 1/2 | 0.860 | 4000 / 273 | 16000 / 1102 | 7.000 / 178 | 330 / 100 |
| G2-10 | 4657-0132 | 5/8 | 0.980 | 3625 / 250 | 14500 / 999 | 8.000 / 203 | 220 / 67 |
| G2-12 | 4657-0128 | 3/4 | 1.140 | 3100 / 214 | 12400 / 854 | 9.500 / 241 | 220 / 67 |
| G2-16 | 4657-0129 | 1 | 1.480 | 2400 / 165 | 9600 / 661 | 12.000 / 305 | 165 / 50 |
| G2-20 | 4657-0644 | 1 1/4 | 1.870 | 1825 / 126 | 7300 / 503 | 16.500 / 419 | 120 / 36 |
| G2-24 | 4657-2491 | 1 1/2 | 2.150 | 1300 / 90 | 5000 / 345 | 20.000 / 508 | 120 / 36 |
| G2-32 | 4657-2492 | 2 | 2.650 | 1175 / 81 | 4500 / 310 | 25.000 / 635 | 120 / 36 |
¥ Pricing & availability on request, contact us. Minimum purchase quantity may apply.
Additional information
| Model | G2-03, G2-04, G2-06, G2-08, G2-10, G2-12, G2-16, G2-20, G2-24, G2-32 |
|---|
