G1 1 Wire Braid Hose
$21.259 – $160.514 ex GST
Description
G1 1 Wire Braid Hose – SAE 100R1 Type AT
G1 1 Wire Braid Hose is a versatile hydraulic hose that offers a high working pressure and is suitable for use in a wide range of applications, including agriculture, construction, and material handling.
Recommended For: Medium pressure hydraulic lines. Meets or exceeds the requirements of SAE 100R1 Type AT and performance requirements of EN 853 1SN.
Tube: Black, oil-resistant synthetic rubber (Nitrile-Type C)
Reinforcement: One braid of high-tensile steel wire.
Cover: Black, oil and abrasion resistant synthetic rubber (Modified Nitrile).
Temperature Range: -40°C to +100°C
Fittings: (see crimp manuals for specifics):
PC Fittings for -03
MegaCrimp® Fittings (except -24 and -32).
GSP Fittings for -24 and -32
D1 Hydraulic Hose – Product Download
| MJ Hydraulic Part Number | Gates Desc. | Hose ID | Working pressure (PSI/Bar) | Min. Burst pressure (PSI/Bar) | Min. bend radius (inch/mm) | Approx. bulk carton length (ft/M) | |
| inch | mm | ||||||
| G1-03¥ | 4657-0599 | 3/16 | 0.470 | 3625 / 250 | 14500 / 999 | 3.500 / 89 | 440 / 134 |
| G1-04 | 4657-0120 | 1/4 | 0.530 | 3275 / 226 | 13100 / 903 | 4.000 / 102 | 440 / 134 |
| G1-05¥ | 4657-0116 | 5/16 | 0.590 | 3125 / 215 | 12500 / 861 | 5.000 / 127 | 550 / 168 |
| G1-06 | 4657-0121 | 3/8 | 0.690 | 2600 / 179 | 10400 / 717 | 5.000 / 127 | 385 / 117 |
| G1-08 | 4657-0122 | 1/2 | 0.820 | 2325 / 160 | 9300 / 641 | 7.000 / 178 | 330 / 101 |
| G1-10 | 4657-0115 | 5/8 | 0.940 | 1900 / 131 | 7600 / 524 | 8.000 / 203 | 220 / 67 |
| G1-12 | 4657-0123 | 3/4 | 1.100 | 1525 / 105 | 6100 / 420 | 9.500 / 241 | 220 / 67 |
| G1-16 | 4657-0124 | 1 | 1.410 | 1275 / 88 | 5100 / 351 | 12.000 / 305 | 165 / 50 |
| G1-20 | 4657-0646 | 1 1/4 | 1.710 | 925 / 64 | 3700 / 255 | 16.500 / 419 | 100 / 30 |
| G1-24 | 4657-2489 | 1 1/2 | 1.960 | 725 / 50 | 2900 / 200 | 20.000 / 508 | 100 / 30 |
| G1-32 | 4657-2490 | 2 | 2.520 | 600 / 41 | 2700 / 186 | 25.000 / 635 | 100 / 30 |
¥ Pricing & availability on request, contact us. Minimum purchase quantity may apply.
Additional information
| Model | G1-03, G1-04, G1-05, G1-06, G1-08, G1-10, G1-12, G1-16, G1-20, G1-24, G1-32 |
|---|
